YT 1t~20t EOT china widely used electric indoor single girder overhead crane price

Product Categories

Henan Yuantai Crane Machinery Import&Export Co.,Ltd

Contact Now

Place of Origin : Henan, China (Mainland)

Brand Name : YT

Certification : BV;ISO;CE;SGS certifications

Model Number : LD

Rated Lifting Moment : according to the specifide parameters

Rated Loading Capacity : 20t

Max. Lifting Load : 20t

Max. Lifting Height : 30m

Span : 7.5-31.5m

Application : various

Feature : Bridge Crane

MOQ : 1

Price : Negotiation

Packaging Details : electric and other parts are packed by high quality plywood crates, main beam packed by plastic clot

Delivery Time : within 30 days after prepayment

Payment Terms : TT/LC/Others

Supply Ability : 10000 sets per year

Contact Now

YT 1t~20t EOT china widely used electric indoor single girder overhead crane price

Lifting Weight(t)	20
Span(m)	7.5~22.5
Crane Total Weight(t)	5.8t~12.5t
Max. Wheel Pressure(kn)	101.5~152.5
Min.Wheel Pressure(kn)	8.6~22.6
Crane Travelling Mechanism	Working speed(m/min)		20(ground)	30(ground)		cab
	Speed Ratio		58.78	39.38		26.36
	Motor	Type	YSE90L1-4	YSE90L-4		ZDR100-4
		Power(kw)	4*1.5	4*1.5		4*2.2
		Rotational speed(r/min)	1380
Lifting Mechanism(Electric Hoist) &Electric Hoist Travelling Mechanism	Model of Electric Hoist		MD1 model		CD1 model
	Lifting Speed(m/min)		3.5/0.35		4
	Lifting Height(m)		6,9,12,18,24,30
	Traveling Speed(m/min)		20
	Motor		Cone squirrel-cage model
Working Class			A3
Electric Current			380V 50Hz three-phase
Wheel diameter			270mm
Width of rail			37~70mm

Application

Packaging & Shipping

YT 1t~20t EOT china widely used electric indoor single girder overhead crane price

Our Services

After-sale Service

1. One year warranty for whole machines

2. Providing free quick-wear part

3. Low charge for continue maintenance when warranty is expired

4. Exclusive engineer support at any time

5. We can provide free training to end-users

YT 1t~20t EOT china widely used electric indoor single girder overhead crane price
